偏磁下におけるマイナーループを考慮した塊状鉄心渦電流損失解析

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2013/02/01

タイトル(英語): Analysis of Eddy-Current Losses in Solid Iron Under DC-Biased Magnetization Considering Minor Hysteresis Loops

著者名: 島　和男（金沢工業大学工学部電気電子工学科），深見　正（金沢工業大学工学部電気電子工学科），宮田　健治（日立製作所日立研究所モータシステム研究部），李　燦（日立製作所日立研究所モータシステム研究部），古川　陽子（日立製作所日立研究所モータシステム研究部）

著者名(英語): Kazuo Shima (Kanazawa Institute of Technology), Tadashi Fukami (Kanazawa Institute of Technology), Kenji Miyata (Hitachi Research Laboratory, Hitachi, Ltd.), Chahn Lee (Hitachi Research Laboratory, Hitachi, Ltd.), Yoko Furukawa (Hitachi Research Laboratory, Hitachi, Ltd.)

キーワード: 偏磁，増分透磁率，マイナーループ，塊状磁極，表面損失，同期機　　DC-biased magnetization，incremental permeability，minor hysteresis loop，solid pole，surface loss，synchronous machine

要約(英語): In designing solid-pole synchronous machines, it is important to take into account the surface eddy-current losses in the field pole cores. In this study, a solid-iron ring specimen is adopted as an approximate model of solid pole surfaces in order to conduct a fundamental study of the surface losses. The influence of the minor hysteresis loops on the losses under DC-biased magnetization is investigated. The losses in the ring under DC-biased magnetization are measured and analyzed by finite element analysis (FEA). The losses computed by the FEA considering minor loops are nearly the same as those measured. In contrast, the eddy-current losses computed by FEA without considering minor loops are considerably inaccurate because the incremental permeability is overestimated and the skin depth is underestimated. It is important to consider hysteresis for the accurate calculation of the surface eddy-current losses under DC-biased magnetization.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.133 No.2 （2013） 特集：Okinawa型ロボット・組み込みシステム

本誌掲載ページ: 231-239 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/133/2/133_231/_article/-char/ja/
