電流形インバータの直流母線電圧に基づく三相交流電圧の復元波形改善とインバータ条件変化時の特性解析

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2013/03/01

タイトル(英語): Improvement of Restoration Waveform and Characteristic of Three-phase Voltage Based on Detected DC Voltage of Current Source Inverter

著者名: 原　靖幸（長岡技術科学大学），芳賀　仁（長岡技術科学大学），近藤　正示（長岡技術科学大学）

著者名(英語): Yasuyuki Hara (Nagaoka University of Technology), Hitoshi Haga (Nagaoka University of Technology), Seiji Kondo (Nagaoka University of Technology)

キーワード: 電流形インバータ，三相電圧復元，交流電圧センサレス，信頼性，低コスト　　Current Source Inverter (CSI)，three-phase voltage restoration，AC voltage sensor-less，high reliability，low cost

要約(英語): This paper proposes a method to detect the DC voltage in order to restore the three-phase voltage of a current source inverter (CSI). The proposed method obtains the three-phase voltage by using the DC voltage and the switching pattern of the CSI. This study improves the restore waveform by considering the delay of the filter. The proposed method can reduce the distortion at the output voltage crosses. This paper shows the characteristics of the proposed method with the conditions of the CSI, such as the modulation ratio, switching frequency, output frequency, and filter capacitance. The experimental results confirm that the proposed method effectively obtains the three-phase voltage. Furthermore, it clarifies the operation condition to obtain a good restoration waveform through the analysis results.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.133 No.3 （2013） 特集：産業計測制御全般

本誌掲載ページ: 342-349 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/133/3/133_342/_article/-char/ja/
