電流共振形ハーフブリッジコンバータの損失解析に基づく回路設計法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2013/03/01

タイトル(英語): Design Procedure Based on Loss Analysis for a Current Resonant Type Half-Bridge Converter

著者名: 宮脇　慧（長岡技術科学大学），伊東　淳一（長岡技術科学大学），岩谷　一生（TDKラムダ（株））

著者名(英語): Satoshi Miyawaki (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology), Kazuki Iwaya (TDK-Lambda Corporation)

キーワード: DC/DCコンバータ，絶縁形コンバータ，共振形コンバータ，損失解析，電流共振　　DC/DC converter，isolated converter，resonant converter，loss analysis，current resonance

要約(英語): This paper proposes a design procedure in the efficiency of a resonant type half-bridge converter for a high efficiency isolated DC/DC converter. The design procedure is based on the loss calculation. The relationship between the loss element and the efficiency characteristics was clarified. The loss analysis method based on the parameters of the circuit element is formulated. The analysis results agree well with experimental results. In addition, the highest efficiency of 96.8% is obtained using the half-bridge converter. Finally, design procedure in the efficiency was clarified using a design procedure flowchart.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.133 No.3 （2013） 特集：産業計測制御全般

本誌掲載ページ: 360-367 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/133/3/133_360/_article/-char/ja/
