A Large-Capacity Capacitor Simulator with an Inner-Series Resistor

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2013/07/01

タイトル(英語): A Large-Capacity Capacitor Simulator with an Inner-Series Resistor

著者名: Masayuki Okamoto (Ube National College of Technology), Eiji Hiraki (Graduate School of Yamaguchi University), Toshihiko Tanaka (Graduate School of Yamaguchi University), Atsushi Tanaka (The Chugoku Electric Power Co., Inc.)

著者名(英語): Masayuki Okamoto (Ube National College of Technology), Eiji Hiraki (Graduate School of Yamaguchi University), Toshihiko Tanaka (Graduate School of Yamaguchi University), Atsushi Tanaka (The Chugoku Electric Power Co., Inc.)

キーワード: ideal capacitor simulator，supercapacitor simulator，bidirectional dc-dc converter，PWM rectifier，inner-series resistor，single-phase PLL circuit

要約(英語): This paper proposes a universal large-capacity capacitor simulator. The proposed simulator consists of a main chemical capacitor and three-leg IGBTs. One leg of the IGBTs acts as a bidirectional dc-dc converter. The other two legs are used for a single-phase PWM rectifier. In the capacitor-charging operation, the bidirectional dc-dc converter is used as a boost converter. Most of the power supplied by the load is supplied to the utility through the single-phase PWM rectifier. In the capacitor-discharging operation, the bidirectional dc-dc converter acts as a buck converter. Most of the power supplied to the load is from the utility through the single-phase PWM rectifier. A new control method, which can perform as an inner-series resistor in a supercapacitor (SC), is also proposed for an SC simulator. The basic principle of the proposed capacitor simulator is discussed in detail. The validity and high applicability of the proposed large-capacity capacitor simulator are confirmed using PSIM software. A prototype experimental model is constructed and tested. The experimental results demonstrate that the proposed capacitor simulator acts both as an ideal large-capacity capacitor and as an SC with an inner-series resistor.

本誌: IEEJ Journal of Industry Applications Vol.2 No.4 （2013） Special Issue on Power Electronics

本誌掲載ページ: 204-210 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/2/4/2_204/_article/-char/ja/
