構造的制約と電気的制約を考慮したラミネートバスバー設計

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2014/04/01

タイトル(英語): Laminated Bus Bar Design for Power Converter Circuit Considering Structural and Electrical Limitations

著者名: 安東　正登（首都大学東京），和田　圭二（首都大学東京）

著者名(英語): Masato Ando (Tokyo Metropolitan University), Keiji Wada (Tokyo Metropolitan University)

キーワード: ラミネートバスバー，寄生インダクタンス，高速スイッチング，インダクタンスマップ　　laminated bus bar，stray inductance，high-speed switching，inductance map

要約(英語): In order to improve the reliability of a power converter circuit, it is important to analyze the DC-side stray inductance between the DC capacitor and the power devices because this may affect the switching losses, lead to the occurrence of over-voltages in power devices, and increase the short-circuit current. As such, a number of studies have investigated these effects through calculations, experiments, and circuit simulations. However, thus far, no paper has discussed a design of the stray inductance. In this paper, the authors propose a design procedure for the stray inductance of the laminated bus bar for a high-speed switching circuit using SiC power devices. The relationship among the bus bar inductance, the over-voltage, and the short-circuit current is clarified using an analytical MOSFET model. In order to verify the analysis results, an experiment using SiC-MOSFET and SiC-SBD rated at 1,200V is conducted. From these results, the upper and lower limitations of the bus bar inductance for the buck chopper circuit are found, and the design procedure for the wiring structure considering the stray inductance is discussed using the inductance map.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.134 No.4 （2014）

本誌掲載ページ: 447-453 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/134/4/134_447/_article/-char/ja/
