可変誘導性リアクタンス機能を持つ5エレメント多重共振形DC-DCコンバータ

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/01/01

タイトル(英語): A Five-Element Multiplex Resonant Full-Bridge DC-DC Converter with a Variable Inductive Reactance

著者名: 三島　智和（神戸大学大学院海事科学研究科），水谷　大斗（神戸大学大学院海事科学研究科），中岡　睦雄（慶南大学大学院電気エネルギー研究センター）

著者名(英語): Tomokazu Mishima (Graduate School of Maritime Science, Kobe University), Hiroto Mizutani (Graduate School of Maritime Science, Kobe University), Mutsuo Nakaoka (Elec. Energy Saving Research Center, Kyungnam University)

キーワード: 共振形DC-DCコンバータ，高周波（HF）リンク，多重共振，パルス周波数変調，ゼロ電圧ソフトスイッチング（ZVS），ゼロ電流ソフトスイッチング（ZCS）　　resonant dc-dc converter，high frequency (HF)-link，multiplex resonance，pulse-frequency-modulation (PFM)，zero voltage soft switching (ZVS)，zero current soft switching (ZCS)

要約(英語): A five element multiplex resonant (LLCLC) full-bridge DC-DC converter controlled by pulse-frequency-modulation (PFM) is proposed in this paper. The high frequency (HF)-link resonant DC-DC converter proposed herein can perform wide-range output power and voltage regulations with a narrow frequency range owing to an anti-resonant tank which works effectively as a wide-range variable inductor. The advantageous characteristics of the anti-resonant tank provide overcurrent protection in the case of the short-circuited load condition as well as the start-up interval, thus the technical challenges of the conventional LLC DC-DC converter can be overcome, and the reliability of the relevant switch-mode power supplies can be improved. The operating principle of the LLCLC DC-DC converter is described, after which its performance is evaluated in an experimental setup based on the 2.5kW prototype. Finally, the feasibility of the proposed DC-DC converter is discussed from the practical point of view.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.135 No.1 （2015） 特集：半導体電力変換研究会

本誌掲載ページ: 27-38 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/135/1/135_27/_article/-char/ja/
