空間ベクトル変調とデルタ-シグマ変調を組み合わせた高周波単相-低周波三相マトリックスコンバータの出力波形改善

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/01/01

タイトル(英語): Output Waveform Improvement of Single-Phase to Three-Phase Matrix Converter for High-frequency Applications using Delta-Sigma Modulation and Space Vector Modulation

著者名: 中田　祐樹（長岡技術科学大学），伊東　淳一（長岡技術科学大学）

著者名(英語): Yuki Nakata (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

キーワード: PDM制御，ゼロ電圧スイッチング，デルタ-シグマ変調，空間ベクトル変調，非接触給電　　PDM control，zero voltage switching，delta-sigma modulation，space vector modulation，wireless power transfer

要約(英語): This paper discusses pulse density modulation (PDM) control methods for a single-phase to three-phase matrix converter (MC) in high-frequency applications. The proposed circuit is used as an interface converter for a wireless power transfer system. This converter can input a frequency of several hundred kilohertz and output a low frequency, i.e. 50Hz or 60Hz, for commercial power grids. The proposed circuit achieves zero voltage switching operation by using the PDM control method and obtains high efficiency. In this paper, two PDM control strategies are compared: PDM control based on space vector modulation (SVM) (the conventional method) and the proposed PDM method, which combines SVM and delta-sigma modulation. Also, the experimental results of the proposed system will be demonstrated and discussed. As a result, the total harmonic distortion (THD) of the output voltage with the conventional method and the proposed method are 9.05% and 1.87%, respectively, when the modulation ratio is 0.5. Thus, the validity of the proposed method has been confirmed for improvement of the output waveforms.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.135 No.1 （2015） 特集：半導体電力変換研究会

本誌掲載ページ: 58-64 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/135/1/135_58/_article/-char/ja/
