影像磁極に着目した空隙磁束密度分布による表面永久磁石同期電動機の基本設計法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/11/01

タイトル(英語): Basic Design Method for SPMSM Based on Air-gap Magnetic Flux Density Distribution Focusing on Image Magnetic Pole

著者名: 杉山　高洋（日本ムーグ（株）技術部）

著者名(英語): Takahiro Sugiyama (Engineering Group., Moog Japan Co., Ltd.)

キーワード: 表面永久磁石同期電動機，影像磁極，空隙磁束密度分布，基本設計　　surface-mounted permanent magnet synchronous motor，image magnetic pole，air-gap magnetic flux density，basic design

要約(英語): This paper presents a basic design method for the surface-mounted permanent magnet synchronous motor (SPMSM) for both distributed and concentrated windings. The design is based on the air-gap magnetic flux density distribution focusing on the image magnetic pole. The calculus equation of the air-gap magnetic flux density distribution is analytically derived by supposing the magnetic pole is located on the magnet surface and image planes. In this study, a three-phase and double-layer stator winding SPMSM that has a linear demagnetizing characteristic magnet, such as a ferrite or rare-earth magnet is considered. From the required specifications and design conditions, the design target values of the parameters that appear in the voltages equations of the d-q axis coordinate system are calculated. Then, the relational equations for the torque constant, d-axis inductance, copper loss, and the maximum current density are presented as a function of three design parameters under id=0 control. They are the stator stack length, the number of coil turns in series in a phase, and the slot bottom length. Hence, this approach reduces the SPMSM basic design to the problem with these design parameters has to be solved. The proposed method makes it possible to address the concentrated winding as a special case of the distributed winding. The FEA results confirm the validity of the proposed basic design method for both distributed and concentrated windings.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.135 No.11 （2015） 特集：回転機技術

本誌掲載ページ: 1051-1062 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/135/11/135_1051/_article/-char/ja/
