可変界磁機能を有する3次元磁気回路モータの提案

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/11/01

タイトル(英語): Novel Variable-Field Motor with a Three-Dimensional Magnetic Circuit

著者名: 難波　雅史（（株）豊田中央研究所），平本　健二（（株）豊田中央研究所），中井　英雄（（株）豊田中央研究所）

著者名(英語): Masafumi Namba (Toyota Central R&D Labs., INC.), Kenji Hiramoto (Toyota Central R&D Labs., INC.), Hideo Nakai (Toyota Central R&D Labs., INC.)

キーワード: 可変界磁モータ，小型化，高効率化，トロイダル巻，3次元磁気回路，多面ギャップ　　variable-field motor，miniaturization，high-efficiency，toroidal windings，3D magnetic circuit，multi gaps

要約(英語): We propose a novel variable-field motor with toroidal windings to achieve both miniaturization and high efficiency. The proposed motor is characterized by a structure that uses a three-dimensional (3D) magnetic flux to increase the number of torque-generation faces. The 3D structure has prevented an increase of the motor volume due to the addition of the variable field. We investigated the principle of variable field by finite element analyses and experiments. We verified that the induced voltage and the torque can be changed by changing the direct current in the field-excitation winding. Moreover, the efficiency can be improved by changing the direct current.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.135 No.11 （2015） 特集：回転機技術

本誌掲載ページ: 1085-1090 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/135/11/135_1085/_article/-char/ja/
