VR形磁気ギヤの動作原理と基本特性

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/11/01

タイトル(英語): Operation Principle and Basic Characteristics of VR Magnetic Gear

著者名: 加藤　秀紀（（株）デンソー），戸成　辰也（（株）デンソー），福岡　道成（（株）デンソー），中村　健二（東北大学 大学院工学研究科）

著者名(英語): Hidenori Kato (DENSO CORPORATION), Tatsuya Tonari (DENSO CORPORATION), Michinari Fukuoka (DENSO CORPORATION), Kenji Nakamura (Tohoku University, Graduate School of Engineering)

キーワード: 磁束変調型磁気ギヤ，Variable reluctance，渦電流損　　flux modulated type magnetic gear，variable reluctance，eddy current loss

要約(英語): A magnetic gear has advantages with respect to noise and maintainability, and the so-called PM (Permanent Magnet) magnetic gear has been studied, which consists of two magnet rotors and a ferromagnetic pole-piece rotor. In this study, we research a novel magnetic gear that we call a VR (Variable Reluctance) magnetic gear. It consists of a magnet rotor and two ferromagnetic pole-piece rotors to improve its performance. First, we describe the operating principle and compare the charactericstics of the VR magnetic gear with those of the PM magnetic gear by using a finite element analysis. Next, we prototype a VR magnetic gear and demonstrate its validity by experiment.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.135 No.11 （2015） 特集：回転機技術

本誌掲載ページ: 1100-1106 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/135/11/135_1100/_article/-char/ja/
