渦電流ブレーキによる3ポジション揺動型電磁アクチュエータの制動時間の短縮と静止位置精度の向上

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2015/11/01

タイトル(英語): A Three-Position Swing Electromagnetic Actuator with an Integrated Eddy Current Brake for Suppression of the Operating Time and Improvement of the Stopping Accuracy

著者名: 高橋　和希（三菱電機（株）先端技術総合研究所），月間　満（三菱電機（株）先端技術総合研究所），甲斐　孝幸（三菱電機（株）先端技術総合研究所），中川　隆文（三菱電機（株）生産技術センター）

著者名(英語): Kazuki Takahashi (Advanced R&D Center, Mitsubishi Electric Corporation), Mitsuru Tsukima (Advanced R&D Center, Mitsubishi Electric Corporation), Takayuki Kai (Advanced R&D Center, Mitsubishi Electric Corporation), Takafumi Nakagawa (Manufacturing Engineering Center, Mitsubishi Electric Corporation)

キーワード: 電磁アクチュエータ，渦電流ブレーキ，連成解析　　electromagnetic actuator，eddy current brake，combined analysis

要約(英語): A closed-loop control system is commonly used in electromagnetic actuators to ensure operating performance. However, this system frequently leads to high costs. We developed a swing electromagnetic actuator with an integrated eddy current brake to reduce the operating time and improve the stopping accuracy. The developed actuator is a three-position cylindrical actuator moving within a ±120-degree angle without closed-loop control. The rotor is composed of a bulk and thin metal laminations and the stator has three sets of pairs of coils. The rotor is stopped at an intermediate position by magnetic force generated by the coils. This paper describes the electromagnetic design and its evaluation by using an FEM simulation to predict its operating characteristics and measure its performance on a test bench. The superiority of our actuator design is verified by comparing these measurements. The operating time is reduced to one-sixth of that of a laminated rotor and the over-travel is compressed to zero. In addition, this actuator has the advantage that it is electrically robust against variations in the power supply.
