Analysis and PCB Design of Class D Inverter for Wireless Power Transfer Systems Operating at 13.56MHz

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2015/11/01

タイトル(英語): Analysis and PCB Design of Class D Inverter for Wireless Power Transfer Systems Operating at 13.56MHz

著者名: Nguyen Kien Trung (Graduate School of Engineering and Science, Shibaura Institute of Technology), Takuya Ogata (Graduate School of Engineering and Science, Shibaura Institute of Technology), Shinichi Tanaka (Graduate School of Engineering and Science, Shi

著者名(英語): Nguyen Kien Trung (Graduate School of Engineering and Science, Shibaura Institute of Technology), Takuya Ogata (Graduate School of Engineering and Science, Shibaura Institute of Technology), Shinichi Tanaka (Graduate School of Engineering and Science, Shibaura Institute of Technology), Kan Akatsu (Graduate School of Engineering and Science, Shibaura Institute of Technology)

キーワード: class D inverter，high frequency inverter，PCB design，wireless power transfer (WPT)

要約(英語): This paper presents the analysis and PCB design of a class D inverter for wireless power transfer systems operating at 13.56MHz. The effects of parasitic inductance on the switching performance of MOSFETs, transfer efficiency of WPT systems, and power loss are analyzed. At high frequencies, the print circuit board (PCB) design is very critical because it control the parasitic elements on the circuit. This study proposes an improved PCB design that can provide a 23.4% decrease in parasitic inductance over the conventional PCB design.

本誌: IEEJ Journal of Industry Applications Vol.4 No.6 （2015）

本誌掲載ページ: 703-713 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/4/6/4_703/_article/-char/ja/
