Minimization of Passive Components in Multi-level Flying Capacitor DC-DC Converter

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2016/01/01

タイトル(英語): Minimization of Passive Components in Multi-level Flying Capacitor DC-DC Converter

著者名: Asmarashid Bin Ponniran (Nagaoka University of Technology), Koji Orikawa (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

著者名(英語): Asmarashid Bin Ponniran (Nagaoka University of Technology), Koji Orikawa (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

キーワード: flying capacitor boost converter，inductor，inductor current ripple，flying capacitor，flying capacitor voltage ripple

要約(英語): In this paper, we propose a minimization design method of the inductance and the capacitance of the flying capacitors for a multi-level flying capacitor DC-DC boost converter (FCBC). The effectiveness of the small capacitances of the flying capacitors in three-level and five-level FCBCs is investigated. We experimentally confirmed that the distortion of the voltage across the input source and the input inductor is drastically reduced by increasing the number of levels. Thus, a small inductance value and a small capacitance value can be used for the input inductor and the flying capacitors, respectively, in an n-level FCBC. Therefore, the minimization of passive components in multi-level FCBCs is achieved. Moreover, the achieved maximum efficiencies of the designed three-level and five-level FCBCs are 98.5% and 97.8%, respectively, at an output power of 1kW.

本誌: IEEJ Journal of Industry Applications Vol.5 No.1 （2016）

本誌掲載ページ: 2023/10/11 p

原稿種別: 研究開発レター／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/5/1/5_10/_article/-char/ja/
