IGBTレグとMOSFETレグを備えたオールメタル対応誘導加熱システム用フルブリッジ・ハーフブリッジ切り替えインバータ

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2016/07/01

タイトル(英語): Full-bridge/Half-bridge Switching Inverter with IGBT Leg and MOSFET Leg for All-metals Induction Heating Systems

著者名: 庄司　浩幸（（株）日立製作所 研究開発グループ／茨城大学），宇留野　純平（（株）日立製作所 研究開発グループ），磯貝　雅之（日立アプライアンス（株）），柳平　丈志（茨城大学）

著者名(英語): Hiroyuki Shoji (Hitachi, Ltd., Research & Development Group/Ibaraki University), Junpei Uruno (Hitachi, Ltd., Research & Development Group), Masayuki Isogai (Hitachi Appliances, Inc.), Takeshi Yanagidaira (Ibaraki University)

キーワード: 高周波インバータ，ソフトスイッチング，PAM制御，誘導加熱　　high-frequency inverter，soft switching，PAM control，induction heating

要約(英語): An induction heating system is proposed as a new circuit topology for induction heating cookers that can be used with all metals. This system has the mechanism to drive an IGBT and a MOSFET in parallel that switch the inverter between full-bridge or modified half-bridge configuration according to the cookware material. When cookware made of a low-resistivity material such as copper or aluminum is heated, the inverter is switched to the half-bridge configuration, which turns off the IGBT leg earlier than the MOSFET leg. When cookware made of a high-resistivity material such as iron or magnetic stainless steel is heated, the inverter is switched to the full-bridge configuration. We confirmed a turn-off timing for the IGBT where the loss of the switching element in the parallel drive was minimized by an experiment. The proposed inverter effectively improved the electricity conversion efficiency for all metals pan heating with the utilized IGBT and MOSFET legs.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.136 No.7 （2016） 特集：家電・民生技術

本誌掲載ページ: 443-449 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/136/7/136_443/_article/-char/ja/
