SiC MOSFETと協調制御方式を用いた高効率太陽光発電用パワーコンディショナの検証

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2016/07/01

タイトル(英語): Performance Verification of High-Efficiency PV Power Conditioner Integrated with SiC MOSFETs and Cooperative Control Method

著者名: 網本　健志（三菱電機（株）），奥田　達也（三菱電機（株））

著者名(英語): Takeshi Amimoto (Mitsubishi Electric Corporation), Tatsuya Okuda (Mitsubishi Electric Corporation)

キーワード: パワーコンディショナ，昇圧コンバータ，インバータ，協調制御，キャリア比較PWM方式，SiC MOSFET　　power conditioner，boost chopper，inverter，cooperation control，carrier comparison PWM method，SiC MOSFET

要約(英語): A high conversion efficiency is always required for photovoltaic power conditioners to utilize PV-generated DC power with minimal loss. The cooperative control method has been developed as one of the control methods that improves the conversion efficiency, which is applicable to non-isolated power conditioners consisting of a boost converter and an inverter. In the cooperative control method, the boost converter creates part of the AC voltage waveform, and either the boost converter or inverter performs switching only during a required period. Therefore, it has the advantage of reducing switching losses. In this paper, we present a study of a cooperative-control-type power conditioner assuming its use in grid-connected operation and the results of a performance verification of prototype power conditioner. A microcontroller is used for cooperative control. The experimental results show that the prototype power conditioner integrated with SiC MOSFETs and the cooperative control method achieves an efficiency of 97.4% at an output of 5.5kW.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.136 No.7 （2016） 特集：家電・民生技術

本誌掲載ページ: 450-455 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/136/7/136_450/_article/-char/ja/
