磁界共振結合方式の無線充電システムにおけるセンシング機能の広域化手法の提案

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2016/07/01

タイトル(英語): Proposal of Wide-Area Sensing in Wireless Charging System via Magnetic Resonance Coupling

著者名: 並木　政人（中央大学大学院電気電子情報通信工学専攻），中村　壮亮（中央大学大学院電気電子情報通信工学専攻），橋本　秀紀（中央大学大学院電気電子情報通信工学専攻）

著者名(英語): Masato Namiki (Department of Electrical Electronic and Communication Engineering, Chuo University), Sousuke Nakamura (Department of Electrical Electronic and Communication Engineering, Chuo University), Hideki Hashimoto (Department of Electrical Electronic and Communication Engineering, Chuo University)

キーワード: 距離センサ，磁界共振結合，Q値制御アンテナ，結合係数，広域化，センシング　　distance sensor，magnetic resonance coupling，Q controllable antenna，coupling coefficient，wide-area，sensing

要約(英語): Recently, wireless charging via magnetic resonance coupling has gained attention because it has the potential of efficient midrange wireless charging. Here, functions such as sensing at the transmitter and wireless communication from the target are the essential elements to realize a standard wireless charging system. Currently, the sensing and communication protocol of the hardware (i.e., the high-frequency power source and antenna configuration) compatible with wireless charging is gaining attention in terms of its cost and space reduction due to the use of common components for multiple functions. However, this protocol has the problem of narrow effective areas due to the fact that the sensing range depends on the fixed Q factor of the antenna. To overcome this problem, the concept of wide-area sensing based on a Q controllable antenna is proposed, and the effectiveness is verified through a theoretical analysis and an experiment. As a result, it is clarified that the effective area can be expanded up to a ratio of the distance g between the transmitting and receiving antennas to the inner diameter d of the antenna g/d =5.0.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.136 No.7 （2016） 特集：家電・民生技術

本誌掲載ページ: 485-493 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/136/7/136_485/_article/-char/ja/
