大ゲート容量に対応した高周波インバータ向け電流形ゲート駆動回路の実機検証
大ゲート容量に対応した高周波インバータ向け電流形ゲート駆動回路の実機検証
カテゴリ: 論文誌(論文単位)
グループ名: 【D】産業応用部門
発行日: 2018/01/01
タイトル(英語): Evaluation of Current-Source Gate Drive Circuit Applied to High-Frequency Inverter with Large Gate Capacitance
著者名: 提橋 郁人(長岡技術科学大学),伊東 淳一(長岡技術科学大学),折川 幸司(北海道大学)
著者名(英語): Ayato Sagehashi (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology), Koji Orikawa (Hokkaido University)
キーワード: ゲート駆動,高周波スイッチング,電流形,電圧形\gate drive,high frequency switching,current source,voltage source
要約(英語): This paper investigates a switching operation when a current-source gate drive circuit is used for large gate capacitance. The current-source gate drive circuit consists of a voltage source, an input inductor, and switching devices such as an H-bridge inverter. The power consumption of this circuit is reduced in comparison with that of a conventional voltage source gate drive circuit because the energy of the capacitor between a gate and a source is not consumed in gate resistance, which is not required for the current source gate drive circuit. The switching operation of the proposed current source gate drive circuit in the high-frequency inverter is evaluated experimentally. In addition, the power consumption is measured when the switching frequency is changed from 100kHz to 1MHz. As a result, it is confirmed that the power consumption of the current-source gate drive circuit is reduced by 62% compared with that of the voltage source gate drive circuit at 1MHz.
本誌: 電気学会論文誌D(産業応用部門誌) Vol.138 No.1 (2018) 特集:半導体電力変換研究会
本誌掲載ページ: 30-38 p
原稿種別: 論文/日本語
電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/138/1/138_30/_article/-char/ja/
