三相電圧形変換器のためのパルス電圧重畳による新しい二相PWM法の提案とその効果

三相電圧形変換器のためのパルス電圧重畳による新しい二相PWM法の提案とその効果

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2018/02/01

タイトル(英語): Novel Two-Phase PWM Scheme using Pulse-Voltage Injection Method for Three-Phase Voltage-Fed Converters

著者名: 茂木 進一(神戸市立工業高等専門学校 電気工学科)

著者名(英語): Shin-ichi Motegi (Department of Electrical Engineering, Kobe City College of Technology)

キーワード: 三相電圧形変換器,パルス幅変調,二相PWM法,高調波,スイッチング損失  three-phase voltage-fed converter,pulse width modulation,two-phase PWM scheme,harmonics,switching losses

要約(英語): Three-phase voltage-fed converters, which are based on the two-phase PWM scheme offer higher ac voltage, lower switching times, and lower switching losses compared with those based on the three-phase PWM scheme. However, the harmonics of the ac-side voltages and currents produced using a two-phase PWM scheme are distributed over a wide frequency range, and this can be a significant drawback for certain applications. To overcome this problem, the author proposes a novel two-phase PWM scheme using pulse-voltage injection method. With the proposed PWM scheme, the harmonics appears in a narrow frequency range, similar to that obtained with the conventional three-phase PWM scheme. In this paper, the author presents experimental results that validate the proposed PWM scheme.

本誌: 電気学会論文誌D(産業応用部門誌) Vol.138 No.2 (2018) 特集:J-RAIL 2016

本誌掲載ページ: 113-121 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/138/2/138_113/_article/-char/ja/
