Si傾斜磁性材料を適用した焼きばめモータの数値解析

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2018/02/01

タイトル(英語): Numerical Simulation of Shrink-fit Motor using Gradient Si Steel

著者名: 小関　新司（JFEスチール スチール研究所），尾田　善彦（JFEスチール スチール研究所），平谷　多津彦（JFEスチール スチール研究所），笠井　勝司（JFEスチール スチール研究所），財前　善彰（JFEスチール スチール研究所）

著者名(英語): Shinji Koseki (Steel Research Laboratory, JFE Steel Corporation), Yoshihiko Oda (Steel Research Laboratory, JFE Steel Corporation), Tatsuhiko Hiratani (Steel Research Laboratory, JFE Steel Corporation), Shoji Kasai (Steel Research Laboratory, JFE Steel Co

キーワード: 鉄損，電磁鋼板，Si傾斜磁性材料，焼きばめ，圧縮応力，モータ　　iron loss，electrical steel sheet，gradient Si steel sheet，shrink-fitting，compressive stress，motor

要約(英語): A gradient Si steel sheet shows low iron loss in the high frequency range and lower iron loss deterioration under compressive stresses, therefore, it is suitable for use as the core material of high-speed motors, which have seen considerable downsizing in recent years. By performing shearing and shrink-fitting, the advantages of gradient Si steel as a motor material are investigated in this study. In both shearing and compressive stress experiments, gradient Si steel showed lower iron loss compared to conventional non-oriented electrical steel (0.2mm thick). By numerical simulation, the efficiencies of the shrink-fitted motors using gradient Si steel and 3%Si steel were calculated. The motor using the gradient Si steel showed significantly higher efficiency than that using the 3%Si steel. Moreover, even under city driving conditions, gradient Si steel showed good efficiency, because of lower iron loss deterioration. Therefore, gradient Si steel can be used for a wide variety of motors in addition to high- frequency devices.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.138 No.2 （2018） 特集：J-RAIL 2016

本誌掲載ページ: 122-127 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/138/2/138_122/_article/-char/ja/
