センサレス永久磁石同期モータのための正相逆相高周波電流相関を用いた離散時間搬送高周波電圧印加法

センサレス永久磁石同期モータのための正相逆相高周波電流相関を用いた離散時間搬送高周波電圧印加法

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2018/02/01

タイトル(英語): Sensorless Vector Control of PMSM using Positive- and Negative-Phase High-Frequency Currents Correlation Signal by Discrete-Time Voltage Injection of PWM Carrier Frequency

著者名: 細岡 竜(神奈川大学大学院工学研究科),中村 直人(神奈川大学大学院工学研究科),新中 新二(神奈川大学大学院工学研究科)

著者名(英語): Ryu Hosooka (Department of Graduate School of Engineering, Kanagawa University), Naoto Nakamura (Department of Graduate School of Engineering, Kanagawa University), Shinji Shinnaka (Department of Graduate School of Engineering, Kanagawa University)

キーワード: 同期モータ,センサレス,高周波電圧印加,PWM,音響ノイズ  synchronous motor,sensorless,high frequency voltage injection,PWM,acoustic noise

要約(英語): This paper presents a new sensorless vector control method for permanent-magnet synchronous motors (PMSMs) that employs discrete-time high-frequency voltage injection. The frequency range of the injected voltage is almost the same as that of the pulse width modulation (PWM) carrier of the voltage command. This allows high-speed phase estimation and high-performance drive, and possibly low acoustic noise caused by the injected voltage. The current associated with the injected voltage, which has a frequency almost equal to the carrier frequency, must be analyzed in a discrete-time manner. This is because, a simple approximation of the continuous-time analysis of the high-frequency current cannot be applied in the range of the carrier frequency. Based on discrete-time analysis, this paper reconstructs the conventional rotor phase estimation methods using positive- and negative-phase high-frequency current correlation signals. The usefulness of the proposed method is verified through extensive experiments.

本誌: 電気学会論文誌D(産業応用部門誌) Vol.138 No.2 (2018) 特集:J-RAIL 2016

本誌掲載ページ: 150-163 p

原稿種別: 論文/日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/138/2/138_150/_article/-char/ja/
