新幹線変電所の避雷器故障予兆検出装置の開発

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2018/03/01

タイトル(英語): Development of a Detection Device For Deteriorated ZnO Surge Arresters at AC Traction Substations

著者名: 赤木　雅陽（鉄道総合技術研究所），田中　弘毅（西日本旅客鉄道（株）），今村　英樹（西日本旅客鉄道（株））

著者名(英語): Masataka Akagi (Railway Technical Research Institute), Hiroki Tanaka (West Japan Railway Company), Hideki Imamura (West Japan Railway Company)

キーワード: 交流き電用変電所，酸化亜鉛形避雷器，漏れ電流，ZnO素子劣化，ロゴウスキーコイル　　AC traction substation，ZnO surge arrester，leakage current，deterioration of the ZnO elements，Rogowski coil

要約(英語): This paper presents a novel detection device for deteriorated zinc-oxide (ZnO) surge arresters. It is necessary to understand the state of ZnO surge arresters for AC traction substations under operation. The waveform distortion of leakage currents can be detected through an increase in multiple harmonic currents; therefore, this effect was employed to develop a device for diagnosing damage to the surge arrester. By adopting a Rogowski coil and band-pass filters, we can obtain more output of the 5th-15th order harmonic currents in comparison with conventional devices. If the threshold value of harmonic elements is exceeded, the lights on the device may light up to indicate the deterioration. The validity of the device was verified by artificial deterioration tests using damaged ZnO elements and a capacitor. This developed device could indicate the soundness of the surge arresters that are in proper working order while being under the influence of feeding voltages, which include harmonic voltages.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.138 No.3 （2018） 特集：スマートな社会を支えるインフラ・設備関連技術

本誌掲載ページ: 242-249 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/138/3/138_242/_article/-char/ja/
