先進マルチレベル変換器と機械スイッチを併用した高圧ハイブリッド直流遮断器

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2018/03/01

タイトル(英語): A High-Voltage Hybrid DC Circuit Breaker Combining Mechanical Switches and an Advanced Multilevel Converter

著者名: 鈴木　敦詞（東京工業大学 工学院電気電子系），赤木　泰文（東京工業大学 工学院電気電子系）

著者名(英語): Atsushi Suzuki (Department of Electrical and Electronic Engineering, Tokyo Institute of Technology), Hirofumi Akagi (Department of Electrical and Electronic Engineering, Tokyo Institute of Technology)

キーワード: 直流送電，ハイブリッド直流遮断器，マルチレベル変換器　　HVDC transmission systems，hybrid dc circuit breakers，multilevel converters

要約(英語): This paper presents a high-voltage hybrid dc circuit breaker that produces no conducting power loss during normal operating conditions and that has the capability to interrupt a large amount of short-circuit current within several milliseconds. It consists of a current-limiting inductor, a current-control inductor, the following two mechanical switches; a low-voltage quasi circuit breaker (LV-qCB) and a high-speed disconnecting switch (HS-DS), and an advanced multilevel converter based on the cascade connection of multiple single-phase bridge cells. This hybrid dc circuit breaker is characterized by achieving current commutation from the LV-qCB to the multilevel converter capable of fast current control. This circuit configuration makes it possible to eliminate power switching devices from the main current path. This elimination leads to producing no conducting power loss during normal operating conditions. This paper provides a theoretical and experimental discussion on the operation, control, and performance of the hybrid dc circuit breaker. It includes verification through a downscaled experimental system rated at 300 Vdc and 150Adc, as well as confirmation through circuit simulation using the “PSCAD” software package.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.138 No.3 （2018） 特集：スマートな社会を支えるインフラ・設備関連技術

本誌掲載ページ: 265-272 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/138/3/138_265/_article/-char/ja/
