力率改善回路付コンバータを用いた傾きを変更したのこぎり波乗算波形による無効電力制御の実験検証

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2019/09/01

タイトル(英語): Experimental Study on Slope Modified Sawtooth Multiplying Reactive Power Control by Using Power Factor Correction Converter

著者名: 近藤　健一（東京大学大学院 工学系研究科），馬場　旬平（東京大学大学院 新領域創成科学研究科）

著者名(英語): Ken-ichi Kondo (Graduate School of Engineering, The University of Tokyo), Jumpei Baba (Graduate School of Frontier Sciences, The University of Tokyo)

キーワード: 無効電力制御，電力変換器，電圧逸脱，配電系統，高調波電流　　reactive power control，converter，voltage violation，distribution line，harmonic currents

要約(英語): Recently, the reverse power flow of photovoltaics during daytime and the concentration of electric vehicle charging at night have caused voltage violation in distribution lines. One of the methods to regulate the distribution line voltage and suppress voltage violation is to control the reactive power by using grid side equipment and distributed generators. However, the installation cost of grid side equipment and the possibility of output power reduction of distributed generators are obstacles with regard to controlling the reactive power. In this research, to reduce the additional installation cost of grid side equipment and to avoid reduction in distributed generator output power, reactive power control by using power factor correction (PFC) converters in consumer loads is introduced and its control ability is evaluated through experiments. Its effect on PFC converter output voltage ripple is also evaluated. From the experiments, the reactive power control ability with the use of PFC converters is verified, and it is found that the increase in output voltage ripple is not large. The proposed reactive power control method can achieve reactive power control by using consumer loads.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.139 No.9 （2019） 特集：家電・民生技術

本誌掲載ページ: 791-799 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/139/9/139_791/_article/-char/ja/
