埋込磁石同期モータの拡張誘起電圧モデルに基づく低速域位置センサレス制御の信号重畳に対する効率評価

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2019/09/01

タイトル(英語): An Efficient Evaluation of Signal Injection Method for Position Sensorless Control of IPMSMs based on an Extended EMF Model at Low-Speed Range

著者名: 齋藤　亮（（株）リンクス），山本　拓也（沼津工業高等専門学校），道木　慎二（名古屋大学 大学院工学研究科 情報・通信工学専攻），大沼　巧（沼津工業高等専門学校）

著者名(英語): Ryo Saito (LINX Corporation), Takuya Yamamoto (National Institute of Technology, Numazu College), Shinji Doki (Department of Information and Communication, Graduate School of Engineering, Nagoya University), Takumi Ohnuma (National Institute of Technology, Numazu College)

キーワード: 埋込磁石同期モータ，センサレス制御，信号重畳，拡張誘起電圧，効率　　IPMSM，sensorless control，signal injection，extended electromotive force (EEMF)，efficiency

要約(英語): This paper presents signal conditions taking motor efficiency into account for position sensorless control of interior permanent magnet synchronous motors (IPMSMs). Signal injection is necessary for position estimation based on an extended electromotive force (EEMF) model at standstill and low speeds. We have proposed a maximum torque control reference frame and the EEMF model suitable for signal injection, and we executed sensorless control in the entire driving area. However, its effects on motor efficiency have not been evaluated in the previous study. Therefore, in this paper, we optimize the amplitude, phase, and frequency of signal current. Moreover, we applied a signal current amplitude adjusting method. This method makes the signal current amplitude minimum based on the EEMF. As a result, we can maintain constant efficiency including copper loss and other losses of the motor, regardless of the signal frequency. The signal frequency can be freely selected in terms of the motor efficiency, so that the proposed method can improve the flexibility to design the injection signals for the position sensorless control of the IPMSMs.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.139 No.9 （2019） 特集：家電・民生技術

本誌掲載ページ: 824-831 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/139/9/139_824/_article/-char/ja/
