帯電物体が体積（奥行き）の異なる非接地の金属筐体から遠ざかるときに生じる静電誘導電圧

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2020/10/01

タイトル(英語): Generation of Electrostatically Induced Voltage When Charged Body Moves Away from Ungrounded Metal Box of Different Volume (Depth)

著者名: 市川　紀充（工学院大学 電気電子工学科），山下　格幸（工学院大学 電気電子工学科）

著者名(英語): Norimitsu Ichikawa (Department of Electrical & Electronic Engineering, Kogakuin University), Noriyuki Yamashita (Department of Electrical & Electronic Engineering, Kogakuin University)

キーワード: 帯電物体，静電誘導電圧，非接地金属筐体，帯電物体の移動，異なる体積（奥行き），静電気　charged body，electrostatically induced voltage，ungrounded metal box，move of charged body，different volume (depth)，static electricity

要約(英語): Static electricity is used for industrial application of copiers etc. However, such applications could experience an electrostatic accident such as a malfunction or failure of the electronic device. For example, when a charged object, such as a charged human body, exists near a metal housing case, such as an electronic device, an electrostatically induced voltage is generated in the metal case. In general, a malfunction or failure of electronic parts is occasionally caused by a voltage of less than 10V. On the one hand, the voltage of a walking human body in an office with an air conditioner could occasionally exceed 10kV. Very often, an office premises comprises several ungrounded metal housing cases with different volumes (depths). In this study, the relationship between the induced voltages and volume (depth) of a metal case was experimentally determined when a charged object moved away from the metal cases of different volumes. The result shows that the induced voltage in the metal case is 1.4 times higher than the induced voltage on the metal case. The induced voltage in the metal case is overall 0.6 times the reverse voltage polarity against the voltage of the charged object when the volume (depth) of the metal case increases. The result of this study will be helpful for considering the preventive measures of a malfunction or failure of electronic equipment caused by the movement of a charged body.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.140 No.10 （2020） 特集：IoT時代を支えるスマートファシリティ関連技術

本誌掲載ページ: 731-737 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/140/10/140_731/_article/-char/ja/
