三相変圧器の零相電流を用いたDC-DCコンバータ回路の検討

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2020/10/01

タイトル(英語): Study on a DC-DC Converter using a Three-Phase Transformer with Zero-Phase Current

著者名: 糸川　祐樹（三菱電機（株）先端技術総合研究所），網本　健志（三菱電機（株）先端技術総合研究所），川井　由宇（三菱電機（株）先端技術総合研究所），奥田　達也（三菱電機（株）先端技術総合研究所）

著者名(英語): Yuki Itogawa (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Takeshi Amimoto (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Yu Kawai (Advanced Technology R&D Center, Mitsubishi Electric Corp.), Tatsuya Okuda (Advanced Technology R&D Center, Mitsubishi Electric Corp.)

キーワード: DC/DC，双方向コンバータ，高周波絶縁，三相変圧器，ソフトスイッチング　DC/DC，bidirectional converter，high-frequency isolation，three-phase transformer，soft-switching

要約(英語): This paper describes a high-frequency-isolation circuit that uses a three-phase transformer with a zero-phase current. The proposed circuit contains a bidirectional chopper circuit and a three-phase high-frequency isolation circuit. The bidirectional chopper circuit controls the DC bus voltage of the first circuit independent from the input voltage source. Thus, the ratio of the DC bus voltage of the first circuit to that of the second circuit can be controlled, which is important in controlling the high-frequency isolation circuit. This study theoretically analyzes the proposed circuit and obtains typical circuit waveforms by simulation. In addition, experimental results using the proposed circuit are discussed. The efficiency of the proposed circuit is measured and compared for each DC bus voltage value. As a result, the proposed circuit can be effectively used for demand control such as in energy storage systems including battery PCS because of its high efficiency using a full-ranged soft-switching technique by controlling the DC bus voltage.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.140 No.10 （2020） 特集：IoT時代を支えるスマートファシリティ関連技術

本誌掲載ページ: 760-768 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/140/10/140_760/_article/-char/ja/
