Theoretical Analysis and Improvement of Output Voltage for Resonant Cockcroft-Walton Circuit

Theoretical Analysis and Improvement of Output Voltage for Resonant Cockcroft-Walton Circuit

通常価格 ¥770 JPY
通常価格 セール価格 ¥770 JPY
セール 売り切れ
税込

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門(英文)

発行日: 2021/03/01

タイトル(英語): Theoretical Analysis and Improvement of Output Voltage for Resonant Cockcroft-Walton Circuit

著者名: Masataka Minami (Kobe City College of Technology), Takumi Yasuda (Kobe City College of Technology/Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

著者名(英語): Masataka Minami (Kobe City College of Technology), Takumi Yasuda (Kobe City College of Technology/Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

キーワード: Cockcroft-Walton circuit,LC resonance,quality factor,boost ratio

要約(英語): The Cockcroft-Walton (CW) circuit is used in high-voltage low-current apparatuses, such as electron beam irradiation devices and insulation testing devices. The parasitic capacitance of the CW circuit is not considered in the design of a high voltage resonant converter. In the past, it has been clarified that the equivalent capacitor of the CW circuit can be utilized as a resonant capacitor to boost the output voltage. This study derives a theoretical quality factor and an output voltage of a resonant CW circuit, considering the equivalent capacitance and the equivalent conductance. Furthermore, it is revealed that parallel capacitors can improve the quality factor and the output voltage of the CW circuit. Experimental results obtained from the 5-stage resonant CW circuit verify the validity of the theoretical analysis.

本誌: IEEJ Journal of Industry Applications Vol.10 No.2 (2021) Special Issue Ⅰ on “Motion Control and its Related Technologies”  Special Issue Ⅱ on “Advanced Power Electronics Technologies”

本誌掲載ページ: 221-226 p

原稿種別: 論文/英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/10/2/10_20001884/_article/-char/ja/
