双方向電力変換可能な二相変調型モジュラー・マルチレベル変換器の実験検証

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2021/04/01

タイトル(英語): Experimental Verification of Bi-Directional Modular Multilevel Cascaded Converter Suitable for Applying 120-Degree Discontinuous Pulse Width Modulation Maximum

著者名: 大井　一伸（（株）明電舎 研究開発本部／千葉大学 大学院融合理工学府），漆畑　正太（（株）明電舎 研究開発本部），只野　裕吾（（株）明電舎 研究開発本部），佐藤　之彦（千葉大学 大学院工学研究院）

著者名(英語): Kazunobu Oi (Labs. R&D Group, MEIDENSHA CORPORATION/Graduate School of Science and Engineering, Chiba University), Shota Urushibata (Labs. R&D Group, MEIDENSHA CORPORATION), Yugo Tadano (Labs. R&D Group, MEIDENSHA CORPORATION), Yukihiko Sato (Graduate Sch

キーワード: MMCC，二相変調，セル内コンデンサ，循環電流，スナバコンデンサ，サージ電圧，バッファリアクトル　　Modular Multilevel Cascaded Converter，discontinuous PWM maximum，cell capacitor，circulating current，snubber capacitor，surge voltage，buffer reactor

要約(英語): Modular Multilevel Cascaded Converters (MMCCs) have advantages in the application of high or medium voltage without transformers. They can also generate high quality voltage with fewer harmonics. Their unique merits make them leading technology candidates for high/medium voltage applications. However, a concern still exists that the number of parts may be increased. In this study, an MMCC topology using high-voltage IGBT (HV-IGBT) with snubber capacitor connected in parallel as a cell module arm is proposed, by which the number of cells can be halved and conduction loss can be significantly reduced owing to the output current flowing through the HV-IGBT in 1/3 of the cycle. Meanwhile, the proposed control stratagem can control the cell capacitor voltage, suppress the HV-IGHT surge voltage, and avoid short-circuiting of the snubber capacitor by circulating current. This study reports the evaluation results of capacitors and the experimental results of bi-directional active power conversion operation.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.141 No.4 （2021） 特集：半導体電力変換研究会

本誌掲載ページ: 293-303 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/141/4/141_293/_article/-char/ja/
