高速IPMSMにおける最適パルスパターンによるステータ鉄心の鉄損低減

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2021/04/01

タイトル(英語): Reduction of Iron Loss in Stator Core using an Optimum Pulse Pattern for High-Speed IPMSM

著者名: 熊谷　崇宏（長岡技術科学大学），伊藤　健（長岡技術科学大学），西川　滉大（長岡技術科学大学），伊東　淳一（長岡技術科学大学），山根　和貴（（株）豊田自動織機），山田　伸明（（株）豊田自動織機），名和　政道（（株）豊田自動織機）

著者名(英語): Takahiro Kumagai (Nagaoka University of Technology), Takeshi Ito (Nagaoka University of Technology), Kodai Nishikawa (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology), Kazuki Yamane (TOYOTA Industries Corporation), Nobua

キーワード: 埋込磁石同期電動機，鉄損，最適パルス幅変調　　interior permanent magnet synchronous motor，iron loss，optimum pulse width modulation

要約(英語): This study proposes a reduction method for iron loss in stator core using the optimum pulse pattern for a high-speed interior-permanent-magnet-synchronous-motor (IPMSM). In this paper, a simple evaluation function for iron loss of stator core in a pulse-width-modulation (PWM) drive is introduced. In particular, the iron loss in stator core is approximately estimated from the flux level obtained from the integral of the line-to-line voltage of the PWM drive. In addition, the pulse pattern is optimized to reduce the iron loss in stator core based on the introduced evaluation function. To validate the evaluation function, the correlation coefficient between the evaluation value and the measured iron loss is calculated in 12 random pulse patterns applied to the inductor and IPMSM. As a result, the correlation coefficients are 0.991 and 0.982 in the inductor and IPMSM, respectively. In addition, the iron loss of the IPMSM with the optimum pulse pattern is reduced by 8.5% and 3.7% in comparison with a carry-asynchronous PWM and carry-synchronous PWM, respectively.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.141 No.4 （2021） 特集：半導体電力変換研究会

本誌掲載ページ: 313-323 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/141/4/141_313/_article/-char/ja/
