信号と電力の両方を伝送可能なSAWフィルタを用いたゲート駆動回路

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2021/04/01

タイトル(英語): Gate Drive Circuit Using SAW Filter Capable of Power and Signal Transmissions

著者名: 徳山　寛（東京都立大学），和田　圭二（東京都立大学），五箇　繁善（東京都立大学）

著者名(英語): Hiroshi Tokuyama (Tokyo Metropolitan University), Keiji Wada (Tokyo Metropolitan University), Shigeyoshi Goka (Tokyo Metropolitan University)

キーワード: SAWフィルタ，ゲート駆動回路，検波回路　　SAW filter，gate drive circuit，detector circuit

要約(英語): In power converter circuits, a gate drive circuit is connected to the power devices for the switching operation. The gate drive circuit transmits both signal and power to the power devices, simultaneously. At present, multi-level converter circuits using large numbers of devices have been proposed for power electronics circuits, but these are complicated to implement in a circuit. Hence, simplification of the signal and power transmissions of the gate drive circuit is required for circuit implementations. This paper proposes a gate drive circuit using SAW (Surface Acoustic Wave) devices that can transmit signal and power to the power devices, simultaneously. To use the several-hundreds MHz signal output from the SAW filter as the gate signal, this paper presents the design procedure for the internal parameters of the detection circuit that demodulates the signal into a several kHz signal. The usefulness of the proposed design is demonstrated by experimental evaluation of a half-bridge inverter and gate drive circuit with SAW filters.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.141 No.4 （2021） 特集：半導体電力変換研究会

本誌掲載ページ: 324-329 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/141/4/141_324/_article/-char/ja/
