磁界結合型非接触給電システムの送受電回路の分離解析に基づく伝送電力性能の可視化

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2021/04/01

タイトル(英語): Visual Map of Power Transmission of Magnetically Coupled Wireless Power Transfer System Based on Independent Analysis of Transmitter and Receiver Sides

著者名: 武田　広大（東京大学 大学院工学系研究科電気系工学専攻），古関　隆章（東京大学 大学院工学系研究科電気系工学専攻）

著者名(英語): Kodai Takeda (Department of Electrical Engineering and Information Systems, Graduate School of Engineering, The University of Tokyo), Takafumi Koseki (Department of Electrical Engineering and Information Systems, Graduate School of Engineering, The Univer

キーワード: 磁界結合型非接触給電，可視化，電気回路，補償回路　　magnetically coupled wireless power transfer，visualization，electric circuit，compensation circuit

要約(英語): A wireless power transfer (WPT) technology has recently garnered significant attention owing to its advantages of removing wire and mitigating charging concerns. In a conventional resonance-based compensation circuit design, the power transmission characteristics strongly depend on the coupling condition of the transmitter and receiver coils. Therefore, some non-resonance-based designs have been proposed. However, they are complicated and lack the resonance condition; therefore, circuit designers cannot comprehensively understand their power transmission characteristics. This study proposes a visualization method for the power transmission characteristics based on a divided analysis of WPT systems. The proposed visual map, which consists of simple circles and lines, can help in intuitively understanding the tendency of WPT and evaluate the transmission power of the compensation circuits, including the non-resonance condition. The tendency obtained from the visual map was validated via numerical simulations and experiments. The experimental results were significantly consistent with the intuitively estimated tendency and the evaluated power transmission.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.141 No.4 （2021） 特集：半導体電力変換研究会

本誌掲載ページ: 330-338 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/141/4/141_330/_article/-char/ja/
