PMSMの磁気飽和を考慮した鎖交磁束高調波成分推定値を用いたトルクリプル抑制制御

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2021/04/01

タイトル(英語): Torque Ripple Suppression Control in PMSM Using Estimated Harmonic Component of Flux Linkage Considering Magnetic Saturation

著者名: 寺山　祐樹（東京理科大学），星　伸一（東京理科大学）

著者名(英語): Yuki Terayama (Tokyo University of Science), Nobukazu Hoshi (Tokyo University of Science)

キーワード: トルクリプル抑制，トルクリプル推定，鎖交磁束高調波成分，永久磁石同期電動機，磁気飽和，軸間干渉　　torque ripple suppression，torque ripple estimation，harmonic component in flux linkage，permanent magnet synchronous motor，magnetic saturation，cross-coupling

要約(英語): Undesirable torque ripples in permanent magnet synchronous motors occur because of the spatial harmonics of the inductance and permanent magnet fluxes. Previous studies have proposed several methods for suppressing these torque ripples based on mathematical models. However, most of them do not consider the magnetic saturation. Hence, the torque ripple estimation accuracy may deteriorate, and the torque ripple suppression performance is reduced in the magnetic saturation range. Therefore, this paper proposes a torque ripple suppression method by considering the magnetic saturation based on the estimated harmonic component of the flux linkage and clarification of its effectiveness through simulations and experiments. From the experimental results, the proposed method is seen to suppress the 6th-order torque ripple by 69.1%, which is higher than that of the conventional method. Therefore, it is verified that the proposed method can suppress torque ripples, including those in the magnetic saturation range.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.141 No.4 （2021） 特集：半導体電力変換研究会

本誌掲載ページ: 366-373 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/141/4/141_366/_article/-char/ja/
