Implementation and Applications of Grid-Forming Inverter with SiC for Power Grid Conditioning

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/05/01

タイトル(英語): Implementation and Applications of Grid-Forming Inverter with SiC for Power Grid Conditioning

著者名: Tsorng-Juu Liang (Department of Electrical Engineering, National Cheng Kung University), Jiann-Fuh Chen (Department of Electrical Engineering, National Cheng Kung University), Le-Ren Chang-Chien (Department of Electrical Engineering, National Cheng Kung U

著者名(英語): Tsorng-Juu Liang (Department of Electrical Engineering, National Cheng Kung University), Jiann-Fuh Chen (Department of Electrical Engineering, National Cheng Kung University), Le-Ren Chang-Chien (Department of Electrical Engineering, National Cheng Kung University), Jia-You Lee (Department of Electrical Engineering, National Cheng Kung University), Tzung-Lin Lee (Department of Electrical Engineering, National Sun Yat-sen University), Cheng-Chien Kuo (Department of Electrical Engineering, National Taiwan University of Science and Technology), Yu-Jen Liu (Department of Electrical Engineering, National Chung Cheng University), Chao-Tsung Ma (Department of Electrical Engineering, National United University), Wen-Chung Chen (Department of Electrical Engineering, National Cheng Kung University), Kai-Hui Chen (Department of Electrical Engineering, National Cheng Kung University), Guang-Ting Peng (Department of Electrical Engineering, National Cheng Kung University)

キーワード: microgrid，sustainable energy，grid-forming inverter，SiC

要約(英語): Sustainable energy technologies have become promising solutions to global warming and climate change. Operation of the electric power grid has been dominated in the past by synchronous generation, wherein conventional sustainable energy inverters are designed simply to feed maximum real power into the grid. With the increasing penetration of renewable energy, it is undergoing a rapid shift toward the power generation of inverter-based resources (IBRs). As a result, transitioning to a power grid with more IBRs requires introducing advanced inverter technology that can respond to various disturbances in frequency and voltage occurring on the grid. The grid-forming (GFM) inverter equipped with an energy storage system featuring frequency and voltage support functionalities is vital for the stability of the micro power grid system. The GFM inverter also offers PV output smoothing, low voltage ride through, and low frequency ride through. In addition, the GFM inverter functions as a voltage source inverter to supply energy under off-grid state when the main grid is in fault conditions. A SiC-based 30kVA GFM inverter is presented with a 3-phase 3-level neutral-point-clamped (NPC) topology for high-frequency operation to achieve high efficiency and power density. Design challenges in gate driver design, PCB layout, and thermal consideration are addressed. The performances of the designated GFM inverter are measured and tested under on-grid and off-grid operations to verify the functionalities of the advanced inverter, as well.

本誌: IEEJ Journal of Industry Applications Vol.12 No.3 （2023） Special Issue on “IPEC-Himeji 2022”

本誌掲載ページ: 244-253 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/3/12_22006702/_article/-char/ja/
