Control Method for Single-Phase Active Filter Using Universal Smart Power Module (USPM)

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/05/01

タイトル(英語): Control Method for Single-Phase Active Filter Using Universal Smart Power Module (USPM)

著者名: Mana Sakamoto (Nagaoka University of Technology), Hitoshi Haga (Nagaoka University of Technology)

著者名(英語): Mana Sakamoto (Nagaoka University of Technology), Hitoshi Haga (Nagaoka University of Technology)

キーワード: universal smart power module，single-phase active filter，distributed control

要約(英語): Herein, we propose a control method for a single-phase active filter composed of a universal smart power module (USPM). The USPM is a modularization technology concept that comprises various power conversion systems. Depending on the application, the USPM is a full-bridge inverter with a wideband controller and filter, and the power converter is constructed using several USPMs. In this study, the target system was an active filter composed of modules connected in series or parallel to accommodate arbitrary voltage and current capacitances. The proposed method solves the communication delays between the master and slave controllers owing to the distributed control in wireless communications and the interference problem caused by multiple USPM connections. The experimental results of the steady-state response showed that despite the communication delays, the total harmonic distortion (THD) of the input current was improved by up to 63.0%, and the power factor was 0.997. Moreover, load fluctuation experiments confirmed that the system transitioned to a steady -state and operated stably by updating the command value of the slave controller for the first time after the load fluctuation. The harmonic current elimination can be realized as an active filter, and the effectiveness of the proposed method was confirmed.

本誌: IEEJ Journal of Industry Applications Vol.12 No.3 （2023） Special Issue on “IPEC-Himeji 2022”

本誌掲載ページ: 273-280 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/3/12_22006895/_article/-char/ja/
