Study on Interconnecting Operation Control of Electronic Frequency Converters for Shinkansen Realizing the Replacement of Rotary Frequency Changers

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/05/01

タイトル(英語): Study on Interconnecting Operation Control of Electronic Frequency Converters for Shinkansen Realizing the Replacement of Rotary Frequency Changers

著者名: Toshimasa Shimizu (Central Japan Railway Company), Ken Kunomura (Central Japan Railway Company), Hiroki Miyajima (Toshiba Infrastructure Systems & Solutions Corporation), Takumi Nagai (Toshiba Infrastructure Systems & Solutions Corporation)

著者名(英語): Toshimasa Shimizu (Central Japan Railway Company), Ken Kunomura (Central Japan Railway Company), Hiroki Miyajima (Toshiba Infrastructure Systems & Solutions Corporation), Takumi Nagai (Toshiba Infrastructure Systems & Solutions Corporation)

キーワード: static frequency converter，interconnected operation，reference voltage command value adjustment，overload

要約(英語): Since the 1960's, rotary frequency changers (RFCs) have been used as frequency converters applied to AC power supplies of high-speed railways, and they still play a major role today. On the other hand, electronic frequency converters (EFCs), which have advantages compared to RFCs in terms of maintenance cost and energy saving, have been introduced, and we have been working toward increasing the installation ratio of EFCs. As a result of the progress, we have reached a stage where we need to reduce the number of frequency conversion substations (FC-SSs) that require RFCs in order to further increase the installation ratio of EFCs. Under this situation, we studied a new interconnection control technology to realize the interconnection operation with the existing remote power supply systems to replace all RFCs with EFCs at the Nishisagami FC-SS of the Tokaido Shinkansen. In this paper, we present a new control block diagram for the fixed power factor output method voltage control with reference voltage command value adjustment for EFCs, which can prevent overload of a power supply system placed apart while maintaining stable voltage when EFCs are interconnected to distant power supplies.

本誌: IEEJ Journal of Industry Applications Vol.12 No.3 （2023） Special Issue on “IPEC-Himeji 2022”

本誌掲載ページ: 326-333 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/3/12_22007297/_article/-char/ja/
