Load Test Method Using Two Power Supplies for High-Frequency Transformers

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/05/01

タイトル(英語): Load Test Method Using Two Power Supplies for High-Frequency Transformers

著者名: Koji Orikawa (Hokkaido University), Shogo Nishikawa (Murata Manufacturing Co., Ltd.), Satoshi Ogasawara (Hokkaido University)

著者名(英語): Koji Orikawa (Hokkaido University), Shogo Nishikawa (Murata Manufacturing Co., Ltd.), Satoshi Ogasawara (Hokkaido University)

キーワード: high-frequency transformer，load test，power loss measurement

要約(英語): This paper proposes a load test method for high-frequency transformers using two power supplies. In this method, the two power supplies need to supply only the power losses of the transformer because the power is circulated between the primary and secondary sides. Hence, this load test can be performed on high-frequency transformers with capacity higher than that of the power supply without requiring a high-frequency load. The experimental results show that the load test method can be applied to a transformer under a 100kHz sinusoidal voltage/current using two power supplies with a capacity of 50VA/unit, which is much smaller than the rated capacity of the transformer, i.e., 900VA. Furthermore, the load test can be performed at all power factors from 0 to 1. In addition, the experimental results show that using the proposed method, the accuracy of power loss measurement is improved compared with the existing method that obtains the power loss by subtracting the output power from the input power of the transformer.

本誌: IEEJ Journal of Industry Applications Vol.12 No.3 （2023） Special Issue on “IPEC-Himeji 2022”

本誌掲載ページ: 450-458 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/3/12_22007910/_article/-char/ja/
