Modeling, Analysis, and Experimental Validation of Magnetic Geared Linear Motor

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/05/01

タイトル(英語): Modeling, Analysis, and Experimental Validation of Magnetic Geared Linear Motor

著者名: Nguyen Duc Khuong (Graduate School of Engineering Science, Yokohama National University), Tomoyuki Shimono (Faculty of Engineering, Yokohama National University/Kanagawa Institute of Industrial Science and Technology)

著者名(英語): Nguyen Duc Khuong (Graduate School of Engineering Science, Yokohama National University), Tomoyuki Shimono (Faculty of Engineering, Yokohama National University/Kanagawa Institute of Industrial Science and Technology)

キーワード: tubular linear motor，magnetic gear，magnetic geared linear motor，flux density，high thrust force

要約(英語): Investigation of the magnetic flux density and force characteristics is essential to advance the design and development of new motors. This paper proposes a mathematical solution for predicting the flux density distributions in a tubular magnetic geared linear motor capable of generating a high thrust force. The proposed method can calculate both radial and axial components of flux densities while consuming less computing time than the finite element method. The force transmission capacity of the magnetic gear and the thrust of the motor are calculated based on the predicted flux density. In comparing the calculation, finite element analysis, and experimental results the consistency in the results validates the proposed method.

本誌: IEEJ Journal of Industry Applications Vol.12 No.3 （2023） Special Issue on “IPEC-Himeji 2022”

本誌掲載ページ: 475-483 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/3/12_22007992/_article/-char/ja/
