Conducted EMI Simulation for a DC-DC Converter: a DC Brush Motor System Considering Showering Arc at Mechanical Contacts

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/09/01

タイトル(英語): Conducted EMI Simulation for a DC-DC Converter: a DC Brush Motor System Considering Showering Arc at Mechanical Contacts

著者名: Kodai Katagiri (Advanced Technology R&D Center, Mitsubishi Electric Corporation/Nagoya University), Toru Ogawa (Advanced Technology R&D Center, Mitsubishi Electric Corporation), Masayoshi Yamamoto (Nagoya University), Jun Imaoka (Nagoya University), Mamoru Sasaki (Nagoya University)

著者名(英語): Kodai Katagiri (Advanced Technology R&D Center, Mitsubishi Electric Corporation/Nagoya University), Toru Ogawa (Advanced Technology R&D Center, Mitsubishi Electric Corporation), Masayoshi Yamamoto (Nagoya University), Jun Imaoka (Nagoya University), Mamoru Sasaki (Nagoya University)

キーワード: DC brush motor，DC-DC converter，commutation，showering arc，equivalent circuit，electromagnetic noise

要約(英語): This paper provides an overview of a circuit analysis model for a DC brush motor, taking into consideration showering arc events. A mechanical contacts model that reproduces showering arc behavior is developed by combining new variable resistors with the steady arc model. As a result, spike surge waveforms can now be simulated via circuit analysis. It is also become clear that spike surges with continuous showering arcs constitute the maximum condition of conducted EMI. The measured and simulated conducted EMI show good agreement within 9dB up to 108MHz, in accordance with the CISPR 25 standard. Moreover, it is now possible to quantitatively predict the amount of conducted EMI in a system comprising a step-down DC-DC converter and a DC brush motor, by considering a dominant magnetic coupling and parasitic impedances.

本誌: IEEJ Journal of Industry Applications Vol.12 No.5 （2023）

本誌掲載ページ: 933-944 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/5/12_22007677/_article/-char/ja/
