Reduction of Torque Vibration in Integrated On-board Chargers Using Stator Windings of an IPMSM

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/09/01

タイトル(英語): Reduction of Torque Vibration in Integrated On-board Chargers Using Stator Windings of an IPMSM

著者名: Yosuke Ito (Nagaoka University of Technology), Hitoshi Haga (Nagaoka University of Technology)

著者名(英語): Yosuke Ito (Nagaoka University of Technology), Hitoshi Haga (Nagaoka University of Technology)

キーワード: integrated battery charger，IPMSM，torque ripple，back-EMF

要約(英語): This study proposed a control method to reduce the torque ripple vibration of an integrated on-board charger using the windings of an interior permanent magnet synchronous motor (IPMSM). During a battery-charging operation, stopping the motor results in noise, as well as damage to the motor and other components from the torque vibration caused by the charging current. In the proposed control method, the generated torque was estimated using a back-electromotive force table, and the phase current was controlled to eliminate the torque. The proposed method can suppress torque vibration, irrespective of the angle of the rotor in the IPMSM. The effectiveness of the proposed method was verified experimentally, with the torque vibration suppressed by 94% compared with that of the conventional control method.

本誌: IEEJ Journal of Industry Applications Vol.12 No.5 （2023）

本誌掲載ページ: 982-989 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/5/12_22011076/_article/-char/ja/
