Operation Characteristics of Discontinuous Current Mode for a Dual-Active-Bridge AC-DC Converter with an Active Energy Buffer

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2023/09/01

タイトル(英語): Operation Characteristics of Discontinuous Current Mode for a Dual-Active-Bridge AC-DC Converter with an Active Energy Buffer

著者名: Shohei Komeda (Tokyo University of Marine Science and Technology), Shunsuke Takuma (Nagaoka Power Electronics Co. Ltd.), Yoshiya Ohnuma (Nagaoka Power Electronics Co. Ltd.), Ryo Gondo (Yazaki Corporation), Daisuke Maezaki (Yazaki Corporation), Noritaka Taguchi (Yazaki Corporation)

著者名(英語): Shohei Komeda (Tokyo University of Marine Science and Technology), Shunsuke Takuma (Nagaoka Power Electronics Co. Ltd.), Yoshiya Ohnuma (Nagaoka Power Electronics Co. Ltd.), Ryo Gondo (Yazaki Corporation), Daisuke Maezaki (Yazaki Corporation), Noritaka Taguchi (Yazaki Corporation)

キーワード: AC-DC converter，continuous current mode，dual active bridge，power decoupling technique

要約(英語): This paper discusses operation characteristics of discontinuous current mode (DCM) for an ac-dc isolated converter for on-board battery chargers of electric vehicles. The converter discussed in this paper consists of a front-end diode-bridge rectifier, an active energy buffer, and a dual-active-bridge dc-dc converter. The energy buffer circuit absorbs the power pulsation from the single-phase ac line into a small-rated capacitor, and thus, makes it possible to reduce a required capacitance of the dc-link capacitor. This paper explains details of the DCM control method including a technique of the ripple cancel of the inductor current, to realize the power factor correction of the line current and the voltage control of the buffer capacitor at the same time without complex calculations. Then, a reference value of the inductor current and an operation range of the dc-output voltage are discussed. Experimental results obtained by a 220-V, 6.6-kW experimental setup demonstrate a sinusoidal-line current and a controlled buffer capacitor voltage as well as a smoothed dc-output current.

本誌: IEEJ Journal of Industry Applications Vol.12 No.5 （2023）

本誌掲載ページ: 1015-1024 p

原稿種別: 論文／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/12/5/12_22004964/_article/-char/ja/
