ISOP型Solid-State TransformerにおけるPWM駆動と方形波運転を併用したハイブリッド変調法

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2023/12/01

タイトル(英語): Hybrid Modulation Method of PWM and Square-Wave Operation for Single-Phase Solid-State Transformer with ISOP Connection

著者名: 菊地　尚斗（長岡技術科学大学），日下　佳祐（長岡技術科学大学），渡辺　大貴（長岡技術科学大学），伊東　淳一（長岡技術科学大学）

著者名(英語): Naoto Kikuchi (Nagaoka University of Technology), Keisuke Kusaka (Nagaoka University of Technology), Hiroki Watanabe (Nagaoka University of Technology), Jun-ichi Itoh (Nagaoka University of Technology)

キーワード: Solid-State Transformer，力率改善回路，方形波運転，LC共振回路　　Solid-State Transformer，power factor correction circuit，square-wave driving，LC resonant circuit

要約(英語): This paper proposes a hybrid modulation for a solid-state transformer (SST) with an input-series output-parallel (ISOP) connected cells. One of the cells on the high-voltage side for power factor correction (PFC) is driven using pulse width modulation (PWM) to compensate for the harmonic components of the input current, whereas the other cells are driven using square-wave operation. The square-wave operation cell enables the use of low-cost Si devices instead of expensive SiC devices, which reduces the cost of the SST. Moreover, this paper proposes the balancing control of the conduction loss in each square-wave cell. The experimental results demonstrate that the total harmonic distortion of the input current is 2.91%, and the conduction loss of each square-wave cell is well-balanced.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.143 No.12 （2023） 特集Ⅰ：半導体電力変換研究会　特集Ⅱ：家電・民生技術

本誌掲載ページ: 758-765 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/143/12/143_758/_article/-char/ja/
