PMSMの動力線への単相変圧器を用いた位置検出用電力重畳における回路方程式

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門

発行日: 2023/12/01

タイトル(英語): Circuit Equation in Power Superimposition for Position Sensor Using Single-Phase Transformer on PMSM Power Lines

著者名: 桐淵　岳（オムロン（株）／大阪公立大学），井上　征則（大阪公立大学），森本　茂雄（大阪公立大学）

著者名(英語): Takeshi Kiribuchi (OMRON Corporation/Osaka Metropolitan University), Yukinori Inoue (Osaka Metropolitan University), Shigeo Morimoto (Osaka Metropolitan University)

キーワード: 同期電動機，電力変換器，電力重畳，電力線通信　　synchronous motor，power converter，power superimposition，power line communication

要約(英語): Permanent magnet synchronous motors (PMSM) are very popular in the industrial market. Recently, robots are installed to compensate for the shortage of labor. Due to the increase in motors, the number of power lines and position sensor cable wiring are increased; this increase in complicated wiring is a problem. As a method to solve these problems, power superimposition technology in the power line of a PMSM is expected to reduce the distribution cables. In this paper, the power superposition technology method, and circuit equations of mounting transformers in power lines are presented and are then verified by experiment, simulation, and linear analysis. The circuit equation is proposed as a three-phase circuit equation, which is transformed into a dq-circuit equation by a transformation matrix. The characteristics of the electric angular frequency versus the dq-axis voltage demonstrated satisfactory results, with errors within 1% in linear analysis and simulation. The linear analysis and experiment are shown to be similar, although there are some errors. The validity of the circuit equations could be demonstrated by the verification results.

本誌: 電気学会論文誌D（産業応用部門誌） Vol.143 No.12 （2023） 特集Ⅰ：半導体電力変換研究会　特集Ⅱ：家電・民生技術

本誌掲載ページ: 766-775 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejias/143/12/143_766/_article/-char/ja/
