各種PWM法を適用した三相電圧形インバータにおける交流側インダクタの損失比較
各種PWM法を適用した三相電圧形インバータにおける交流側インダクタの損失比較
カテゴリ: 論文誌(論文単位)
グループ名: 【D】産業応用部門
発行日: 2023/12/01
タイトル(英語): Comparison of AC-Side Inductor Loss on Three-Phase Voltage-Fed Inverter with Various PWM Schemes
著者名: 池内 丈人(長岡技術科学大学),茂木 進一(神戸市立工業高等専門学校 電気工学科),伊東 淳一(長岡技術科学大学)
著者名(英語): Taketo Ikeuchi (Nagaoka Univercity of Technology), Shin-ichi Motegi (Dept. of Electrical Engineering, Kobe City College of Technology), Jun-ichi Itoh (Nagaoka Univercity of Technology)
キーワード: 三相電圧形変換器,パルス幅変調,変換効率,損失,高調波 three-phase voltage-fed converter,pulse width modulation,conversion efficiency,power loss,harmonics
要約(英語): In this study, the authors experimentally verify the AC-side inductor loss of the three-phase voltage-fed inverter by evaluating the core temperature. Two-phase pulse width modulation (PWM) is renowned for its low switching losses. However, the harmonics of the AC-side voltages and currents generated by a two-phase PWM are greater than those of a three-phase PWM. Therefore, the increase in power loss due to the harmonics in the inductor connected to the AC side of the inverter is concerning. To address this issue, the authors experimentally verify and evaluate the AC-side waveforms, total harmonic distortion (THD), power dissipation and inductor core temperature, and conversion efficiency for the three-phase voltage-fed inverters with the different PWM schemes. The results demonstrate that the two-phase PWM improves conversion efficiency compared to the three-phase PWM, assuming the same THD as for the three-phase PWM. Additionally, the two-phase PWM reduces the THD compared to the three-phase PWM and reduces the power dissipation and core temperature of the inductor to the same extent as the three-phase PWM method, assuming identical conversion efficiency.
本誌: 電気学会論文誌D(産業応用部門誌) Vol.143 No.12 (2023) 特集Ⅰ:半導体電力変換研究会 特集Ⅱ:家電・民生技術
本誌掲載ページ: 809-816 p
原稿種別: 論文/日本語
