Splitting Conductors of Coils on PCB for AC-resistance Reduction

カテゴリ: 論文誌(論文単位)

グループ名: 【D】産業応用部門（英文）

発行日: 2024/11/01

タイトル(英語): Splitting Conductors of Coils on PCB for AC-resistance Reduction

著者名: Shunsaku Nomoto (Nagaoka University of Technology), Shinjiro Shimura (Nagaoka University of Technology), Keisuke Kusaka (Nagaoka University of Technology), Takashi Takada (AGC Inc.)

著者名(英語): Shunsaku Nomoto (Nagaoka University of Technology), Shinjiro Shimura (Nagaoka University of Technology), Keisuke Kusaka (Nagaoka University of Technology), Takashi Takada (AGC Inc.)

キーワード: skin effect，proximity effect，spiral coil，printed circuit board (PCB)

要約(英語): This letter proposes a method to suppress copper loss due to the skin and proximity effect (AC-resistance) by splitting the conductors of a coil on a printed circuit board (PCB) into some traces and swapping them at the corner of the coil. The proposed structure for the coil is characterized as having no via, which results in an increase in cost and copper loss. The simulation results demonstrate that in the proposed coil comprising 12 corners (12c coil), splitting a conductor into three traces, the resistance is suppressed by 16.7% compared with a spiral coil, and the quality factor is improved by 11.0%. Practical experiments on the prototype of the 12c coil further revealed improvements in the resistance and quality factor by 19.7% and 18.8%, respectively.

本誌: IEEJ Journal of Industry Applications Vol.13 No.6 （2024）

本誌掲載ページ: 743-744 p

原稿種別: 研究開発レター／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejjia/13/6/13_L24000436/_article/-char/ja/
