可視光通信用2眼式受信システムの光学設計と受信特性

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2011/10/01

タイトル(英語): Optical Design and Receiving Characteristics of Two Lens Type Visible Light Communication System

著者名: 松本 佳宣（慶應義塾大学理工学部物理情報工学科），中田 啓道（慶應義塾大学理工学部物理情報工学科）

著者名(英語): Yoshinori Matsumoto (Faculty of Science and Technology, Department of Applied Physics and Physico-Informatics, Keio University), Hiromichi Nakada (Faculty of Science and Technology, Department of Applied Physics and Physico-Informatics, Keio University)

キーワード: 可視光通信，2眼式受信システム，焦点距離，通信距離，フォトトランジスタアレイ　　visible light communication，two lenses type receiving system，focal length，communication length，photo-transistor array

要約(英語): This paper describes the optical design for two lens type visible light communication system to reduce back ground noise. The system is composed of image sensor, receiving element and control software. The selected area for the receiving element was calculated by considering the chip size, focal length of lens and the pitch between image sensor and receiving element on the PCB board. The communication length is expected in proportional to the focal length of lens. LED sources were modulated with sub-carrier 4bit pulse position modulation of visible light ID at the carrier frequency of 28.8kHz. The communicational length of the system by using commercialized high sensitive photo transistor was measured up to 16.5m for the focal length of 12mm. In the photo-transistor array system, the brightness and illuminant size from the image sensor is used to identify the signal source. The system separates the data from multi signal sources by selecting the arbitrary receiving element.

本誌: 電気学会論文誌E（センサ・マイクロマシン部門誌） Vol.131 No.10 （2011） 特集：集積化センサとその設計・製作

本誌掲載ページ: 351-356 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/131/10/131_10_351/_article/-char/ja/
