穿刺用貫通型超音波探触子の基礎特性と針の検出原理

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2012/11/01

タイトル(英語): Basic Properties of an Ultrasonic Probe with a Through Hole for Puncture and Detection Principle of a Puncture Needle

著者名: 田中　雄介（立命館大学），田中　克彦（立命館大学），杉山　進（立命館大学），塩見　尚礼（滋賀医科大学），来見　良誠（滋賀医科大学），谷　徹（滋賀医科大学），高橋　修（ジャパンプローブ（株））

著者名(英語): Yuusuke Tanaka (Ritsumeikan University), Katsuhiko Tanaka (Ritsumeikan University), Susumu Sugiyama (Ritsumeikan University), Hisanori Shiomi (Shiga University of Medical Science), Yoshimasa Kurumi (Shiga University of Medical Science), Tohru Tani (Shiga University of Medical Science), Osamu Takahashi (Japan Probe Co., Ltd.)

キーワード: 超音波，探触子，穿刺，反射，エッジ波　　ultrasonic wave，ultrasonic probe，puncture，reflection，edge wave

要約(英語): We fabricated an ultrasonic probe with a through hole for needle puncture. The probe consists of a ring-shaped transducer around the hole for detecting needle tip and 12 fan-shaped transducers around the ring-shaped transducer for observing a lesion area. A B-mode image was obtained for inserting a needle into the pig liver. We investigated the phase of signals from the needle tip using an ultrasonic probe having separated elements of transmitter and receiver. From the experimental results the detection principle of the needle tip was explained by edge waves.

本誌: 電気学会論文誌E（センサ・マイクロマシン部門誌） Vol.132 No.11 （2012）

本誌掲載ページ: 420-424 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/132/11/132_420/_article/-char/ja/
