バナジウム系ガラスを用いた塗布型熱電変換素子

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2013/07/01

タイトル(英語): Printed Thermoelectric Devices using Vanadate Glass Composite Materials

著者名: 鷹野　秀明（（株）日立製作所 中央研究所），田窪　千咲紀（（株）日立製作所 中央研究所），浅井　健吾（（株）日立製作所 中央研究所），沢井　裕一（（株）日立製作所 日立研究所），藤枝　正（（株）日立製作所 日立研究所），内藤　孝（（株）日立製作所 日立研究所），倉田　英明（（株）日立製作所 中央研究所），後藤　康（（株）日立製作所 中央研究所）

著者名(英語): Hideaki Takano (Hitachi, Ltd., Central Research Laboratory), Chisaki Takubo (Hitachi, Ltd., Central Research Laboratory), Kengo Asai (Hitachi, Ltd., Central Research Laboratory), Yuichi Sawai (Hitachi, Ltd., Hitachi Research Laboratory), Tadashi Fujieda (Hitachi, Ltd., Hitachi Research Laboratory), Takashi Naito (Hitachi, Ltd., Hitachi Research Laboratory), Hideaki Kurata (Hitachi, Ltd., Central Research Laboratory), Yasushi Goto (Hitachi, Ltd., Central Research Laboratory)

キーワード: 熱電変換素子，塗布型，バナジウム系ガラス，エネルギーハーベスティング，排熱回収　　thermoelectric devices，printed，vanadate glass，energy harvesting，waste heat recovery

要約(英語): Thermoelectric (TE) devices have emerged as one of the most promising new technologies for use as sensor module energy harvesters and as waste-heat recovery systems. Low-cost and large-area printed TE devices are suitable because heat sources are widely distributed through-out the environment. In addition, high reliability is also required of the TE materials because the devices are operated in high-temperature environments over long periods of time. In this study, we developed glass matrix TE composite materials that have a higher softening temperature than organic materials. Using low melting point vanadate glasses as the matrix materials, we fabricated n-type Bi2Te3― vanadate glass and p-type Bi0.3Sb1.7Te3―vanadate glass composites. The figure of merit (ZT) of both materials was approximately 0.2 at temperatures between 25 and 300℃. We also fabricated a pair of thermocouple devices using these vanadate glass composites with simple printing process, and an output voltage of 5 mV was obtained when the thermocouple pair was placed on a hot plate heated to 90℃.

本誌: 電気学会論文誌E（センサ・マイクロマシン部門誌） Vol.133 No.7 （2013）

本誌掲載ページ: 280-284 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/133/7/133_280/_article/-char/ja/
