光源の自己結合効果を用いた相反型サニャック干渉光学系と光ファイバ振動センサの検討

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2013/07/01

タイトル(英語): Sagnac Interferometer-type Optical Fiber Vibration Sensor with Reduced Minimum Reciprocal Configuration Using Self-coupling Effect of Light Source

著者名: 熊谷　達也（日立電線（株） 高砂工場），大貫　渉（日立電線（株） 高砂工場），中村　晃之（日立電線（株） 高砂工場）

著者名(英語): Tatsuya Kumagai (TakasagoWorks, Hitachi Cable, Ltd.), Wataru Ohnuki (TakasagoWorks, Hitachi Cable, Ltd.), Teruyuki Nakamura (TakasagoWorks, Hitachi Cable, Ltd.)

キーワード: 自己結合効果，振動センサ，サニャック干渉光学系，光ファイバジャイロ，フィジカルセキュリティ　　self-coupling effect，vibration sensor，Sagnac interferometer，fiber-optic gyroscope，physical security

要約(英語): A Sagnac interferometer based on the fiber-optic gyroscope requires two couplers to constitute a reciprocal optic system. In order to simplify the conventional minimum configuration, we have investigated a single-coupler interferometer with reciprocity using the self-coupling effect of light source. The proposed interferometer was applied to a vibration sensor for physical security technology. At many important facilities, fences with vibration sensors are installed along the boundary of the premises to prevent any intrusion. The optical fiber type is suitable for situations in which the vibration sensors need to be easily fixed to the fences, particularly around intricately shaped premises for monitoring a wide range of areas. The sensor's basic characteristics were compared with conventional and non-reciprocal types and its performance as a vibration sensor was verified. Since it enables the simplification of optical systems and assembly processes, the self-coupled optical pickup is effective in reducing the cost of optical fiber sensors.

本誌: 電気学会論文誌E（センサ・マイクロマシン部門誌） Vol.133 No.7 （2013）

本誌掲載ページ: 314-319 p

原稿種別: 論文／日本語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/133/7/133_314/_article/-char/ja/
