SPICE Modeling of Electrostatic Energy Harvester for Optimal Load Resistance Analysis

カテゴリ: 論文誌(論文単位)

グループ名: 【E】センサ・マイクロマシン部門

発行日: 2015/03/01

タイトル(英語): SPICE Modeling of Electrostatic Energy Harvester for Optimal Load Resistance Analysis

著者名: Keidai Minami (Graduate School of Engineering University of Hyogo), Takayuki Fujita (Graduate School of Engineering University of Hyogo), Toshikazu Onishi (Graduate School of Engineering University of Hyogo), Koji Sonoda (Graduate School of Engineering Un

著者名(英語): Keidai Minami (Graduate School of Engineering University of Hyogo), Takayuki Fujita (Graduate School of Engineering University of Hyogo), Toshikazu Onishi (Graduate School of Engineering University of Hyogo), Koji Sonoda (Graduate School of Engineering University of Hyogo), Naoki Miwatani (Graduate School of Engineering University of Hyogo), Kensuke Kanda (Graduate School of Engineering University of Hyogo), Kazusuke Maenaka (Graduate School of Engineering University of Hyogo)

キーワード: Energy harvester，Electret，SPICE model，Variable capacitor model，Optimal load resistance

要約(英語): This paper presents an equivalent circuit model of an electrostatic energy harvester for a SPICE circuit simulator. The output power and impedance of the proposed model are approximated by using a simplified model of a voltage-controlled capacitor. The relationship between the capacitance and the electrode position is calculated by FEM analysis by taking the fringing effect into account; this relationship is applied to a sub-circuit model for the SPICE simulator. Further, the results of this study show that the output waveform and the optimal resistance obtained using the SPICE simulator correspond with the measurement results. In addition, the operation of a harvesting system connected with a commercially available power management IC is demonstrated.

本誌: 電気学会論文誌E（センサ・マイクロマシン部門誌） Vol.135 No.3 （2015） 特集：センサ・マイクロマシン英文特集号

本誌掲載ページ: 116-117 p

原稿種別: 研究開発レター／英語

電子版へのリンク: https://www.jstage.jst.go.jp/article/ieejsmas/135/3/135_116/_article/-char/ja/
