過負荷保護技術

過負荷保護技術

通常価格 ¥3,300 JPY
通常価格 セール価格 ¥3,300 JPY
セール 売り切れ
税込

カテゴリ: 技術報告

論文No: 1069

グループ名: 【B】電力・エネルギー部門

発行日: 2006/10/25

タイトル(英語): Overload Protection Relay Technology

著者名: 過負荷保護技術調査専門委員会

著者名(英語): Investigating R&D Committee on Overload Protection Relay Technology

キーワード: Power Systems, Overload, Protection Relays, SPS, OLR, Cascading, Blackout

要約(日本語): わが国ではこれまで、経済発展に伴う電力需要の伸びに対応するため、新たな発電所の新増設および送電線や変電所の増強を進めてきた。また、こうした電力系統の増強と協調を図りながら、保護リレーシステムによる事故波及防止対策を整備することによって電力系統の安定運用に万全を期してきた。しかしながら、2004年に北米やイタリアにおいて広範囲かつ長時間におよぶ停電が相次いで発生していることを鑑みると、電力系統を安定運用していくための事故波及防止技術は今後も重要な技術課題であるといえる。一方、エネルギー分野における規制緩和と電力自由化の進展に伴い、設備の有効活用の観点から設備稼働率の向上が期待され、これまで以上に電力系統の過負荷が顕在化することが想定される。このような背景を踏まえ、保護リレーシステムによる事故波及防止技術のうち「過負荷保護技術」について最新の知見の共有化を目的として、保護制御技術に関わる大学、研究所、メーカー、電力会社に在籍する専門家によって構成される調査専門委員会を設置し、2004年8月から2006年7月までの2年間、調査・検討を行った。本報告書は、電力系統の過負荷現象および過負荷保護技術に関して、国内の電力会社における技術動向や過負荷保護リレーシステムの適用実態を整理したものであり、電力系統・設備関係の技術者や電力工学を学ぶ学生の技術資源として活用することができる。

要約(英語): In Japan, electric utilities have applied various kinds of special protection systems (SPS) to prevent major outage. Recently, some foreign countries such as USA or Italy experienced major blackouts, which made us realize again that SPS had important roles to keep power systems stable. Overload relay (OLR) system is a sort of SPS. Every facility in the power system is operated under its capacity in a normal condition. However, if one or some of facilities are shut down due to a fault, the power flow takes a detour through remaining facilities and this could cause overload. Without appropriate actions, overload could cause a major outage due to cascading trips. To prevent a cascading outage, OLR system detects the overload of a facility and takes remedial actions to limit the power flow below its capacity, by increasing, reducing or shutting down the generations or tripping the loads, etc. The Institute of Electrical Engineers of Japan (IEEJ) formed “Investigating R&D Committee on Overload Protection Relay Technology” with protective relay specialists in universities, institutes, manufacturers and utilities and made a survey on OLR systems from August 2004 to July 2006. This report presents the result of the survey, including what is overload, how overload is caused, capacity calculation of facilities, methods for detecting overload, remedial actions against overload, structures of OLR systems and examples of the application of OLR systems, etc.

PDFファイルサイズ: 12,153 Kバイト
